Operating Weight 6,220 lb
Engine Horsepower 46 hp
Engine Model Kubota V2203‑M‑DI diesel
Rated Operating Capacity (ROC) 1,750 lb (ISO)
Tipping Load 4,100 lb
Lift Path Vertical
Hydraulic Pump Flow 16.9 gpm
System Relief Pressure 3,300–3,350 psi
Travel Speed 7.3 mph standard
Height to Hinge Pin 118.2 in
Dump Height 91.0 in
Lift Breakout Force 3,400–3,600 lb
Tilt Breakout Force 3,240–3,550 lb
Controls – Foot; or Selectable Foot/H pattern (Case hand controls)
